With high porosity，large void space,large flux and small resistance,the gas andliquid in the packing tower can pass throughfreely. In this way,the dispersion of liquidincreases and the utilization rate of the innersurface of the packing increases.Therefore,the tower not only has a larger passingcapacity and a lower pressure drop, but alsohas a higher separation efficiency.
Specifications | Path × High × Thick | Specific surface area | Void rate | Stacked quantity | Stacked weight | Dry packing factor |
| φ150 | 15×15×15 | 350 | 0.71 | 250000 | 690 | 960 |
| φ25 | 15×15×15 | 235 | 0.78 | 45200 | 580 | 784 |
| φ40 | 15×15×15 | 178 | 0.75 | 12700 | 550 | 400 |
| φ50 | 15×15×15 | 136 | 0.81 | 6230 | 530 | 305 |
| φ80 | 80×80×8 | 108 | 0.68 | 1900 | 610 | 177 |
| φ100 | 100×100×10 | 90 | 0.7 | 100 | 680 | 234 |
| φ150 | 150×150×15 | 75 | 0.68 | 295 | 690 | 172 |
